More features, more powerful.
The MonsoonX has been upgraded to provide 512 megabytes of data logging, meaning you can log much more data at a faster sample rate. Control loops are also more precise compared to its G4+ predecessor, along with advancements such as single precision floating point format fuel tables, better resolution within ignition timing and faster communications. These upgrades make the G4X Monsoon a true powerhouse in a small shell.
G4X features 512 megabytes of logging at 32bit using up to 250 channels, each limited to up to 1kHz per channel (by the Operating System), with a maximum of 100kHz.
With the MonsoonX you have all the tuning capabilities of the AtomX, but you can also choose to run some of the following features: Launch Control, Anti-lag, VVT Control and Closed Loop Boost Control. It also comes with a built in 4Bar MAP sensor further reducing installation cost.
Note: The MonsoonX will run any of the above features, but it cannot run them all at once. The number of features you can run is dependent on how many of the limited Inputs and Outputs each feature needs.
The MonsoonX will control up to 2 rotors or 4 cylinders with sequential injection and direct spark. This makes it ideal for naturally aspirated or turbocharged engines that just need a retune and one or two extra features, so you don’t need to jump up to one of our higher-level ECUs.
Requires A Loom
- 4 Bar onboard map sensor
- 4 x high current injector drivers
- 4 x ignition outputs
- 4 x auxiliary outputs (Unused ignition drives can be used as auxiliary outputs)
- 4 x digital inputs
- 2 x temperature inputs
- 4 x 0-5v Analog Inputs
- Closed loop boost control
- VVT Control
- Gearshift Control
- Anti Lag
- Launch control
- Wideband O2 (External controller required)
- 32Mb onboard logging
- 20 x General purpose tables
- Onboard diagnostics / channel test features
- 1 x Can bus
- 1 x thirty four pin, waterproof connector
- Compact & lightweight
- Waterproof and dustproof - IP66
The Monsoon comes supplied with waterproof connectors, a mounting bracket and a USB tuning cable.
Please contact us for fitting and mapping services
